This product has now been discontinued, please see the alternative product:
Guide TrackIR Pro 35mm
Handheld Thermal Imaging Monocular
The Guide TrackIR Pro 35mm thermal night vision monocular features a 640x480 IR sensor and 1280x960 HD display. The Guide TrackIR series captures sharp thermal imaging at a 50Hz framerate for smooth vision. Designed to increase situational awareness for different scenes, the TrackIR series features adjustable image quality settings, extended zoom capabilities, picture-in-picture functions and more. The Track IR series are encased in a rugged IP-66 rated housing, delivering over 4.5 hours of battery life, and provides access to multiple software functions allowing for single-handed operation in the toughest conditions, equipping law enforcement professionals, security operators, hunters, and outdoor enthusiasts with reliable thermal imaging to see in absolute darkness.
Features:
- 640x480 IR resolution
- 35mm/F1.0 Focal Length
- 1000m Human Detection Range
- ≥4.5h Operating Time
- ≤50mK NETD
Tactical Ergonomic Design
Thanks to the differential button design, it’s quick and easy to locate and press the button you need through touch, even in total darkness. The streamlined appearance and stable one-hand operation helps avoid fatigue while using it for extended periods
1280×960 HD Display
TrackIR 35mm features a 0.4-inch LCOS display (1280×960 pixels), creating detailed images for clear vision. It feels like you are watching a 22-inch display over 1 meter, greatly improving your observation experience.
Smooth Zoom and Flexible Search
Simply press the Up/Down button to experience the performance-leading zoom capabilities. The smooth digital zoom places 4x more pixels on the scene to locate your target faster.
Stadiametric Rangefinder with High Accuracy
TrackIR 35mm measures the distance of objects with a known height. Take a rabbit (35cm), a wild boar (90cm), and a deer (150cm) as reference. The device or its APP reveals their distance with high accuracy.
User-friendly UI & Powerful Mobile APP
To meet the demands of different users, both the TrackIR 35mm and its APP support photo and video recording, distance measurement, hot spot tracking, switchable color palettes, smooth zoom, adjustable image quality, WiFi, and more.
Multiple Image Modes to Highlight the Target
Switch from “Default” to “Enhanced/Highlight” with the touch of a button to reduce the image impurities and highlight the target effectively.
A Rugged IP-66 Rated Encapsulation
Its PC-ABS and IP-66 rated casing allows operations in extreme environmental conditions and withstands a 1-meter drop. Various certifications including UN38.3, RoHS, CE and FCC gives you the quality assurance you require.
USB Type-C Interface for a Broad Array of Accessories
• Equipped with a standard picatinny rail interface, it can be connected to accessories like external displays and a rangefinder for security, night patrol, law enforcement operations, search & rescue missions and personal safety.
• Type-C USB plus Micro HDMI makes it easy to leave on charge or transmit data.
Applications
Law Enforcement
Outdoor
Low Light Observation
Media Gallery
| Specifications | |
|
Infrared detector |
|
|
Detector resolution and pitch |
640 × 480, 12 μm |
|
Spectral range |
8～14μm |
|
NETD |
≤50mk @ F1 25℃ |
|
Lens |
|
|
Focal length |
35mm F1.0 |
|
Focusing mode |
Manual focusing |
|
Field of view |
12.5° × 9.4° |
|
Frame Rate |
|
|
Output frame frequency |
50Hz |
|
Zoom |
|
|
Optical zoom |
2.0x |
|
Digital zoom |
1 – 8x |
|
Visual effect |
It's like viewing at a 22’‘ screen at a 1 meter |
|
Display |
|
|
Display type |
0.4'' FLCOS |
|
Resolution |
1280 × 960 |
|
Eyepiece |
Monocular, exit pupil distance≥10 mm, diopter adjustment: -4 to＋2 |
|
Eyepiece zoom |
13.8x |
|
Video output |
Digital Video |
|
Button |
|
|
Button Function |
Power / Up / Menu / Down / Photo / Video |
|
System |
|
|
Time setting |
Available |
|
Watermark settings |
Closed, setting of date or date and location |
|
PIP |
Upper left, Upper middle, Upper right, Closed |
|
Restore to default |
Available |
|
Start up |
2 s |
|
Memory capacity |
16 GB |
|
Environmental |
|
|
Operating temperature range |
-10 ℃ to 50 ℃ |
|
Storage temperature range |
-30 ℃ to 60 ℃ |
|
Humidity |
10 % to 95 % non-condensing |
|
Shock |
30 G at 1 ms half sine pulse (as per IEC60068-2-27) |
|
Vibration |
10 Hz - 150 Hz - 10 Hz 0.15 mm (as per IEC60068-2-6) |
|
Drop |
1 m |
|
Encapsulation |
IP66 |
|
Certification |
FCC, CE, Rohs, EAC, un38.3 |
|
Physical |
|
|
Weight |
≤560 g |
|
Size (L × W × H) |
214 × 65 × 71 mm |
|
Standard |
Power adapter, USB cable (Type C), micro HDMI cable, lens cap, wrist strap, inner bag, shoulder strap, quick start guide |
